Product Details
Place of Origin: China
Brand Name: REINFORCE
Certification: ISO9001
Model Number: REINFORCE-66
Payment & Shipping Terms
Minimum Order Quantity: 1000 square meter
Price: USD 1.7-3/ square meter
Packaging Details: steel strip six rolls each bundle
Delivery Time: 14-30works day
Payment Terms: T/T
Supply Ability: 2000 Square meters per week
Product Name: |
Subsea Force Reingrid Subsea Pipeline Reinforced Mesh |
Key Words: |
Offshore Pipeline Counterweight Welded Wire Mesh |
Material: |
Cold Or Hot-dip Galvanized |
Line Wire Quantity: |
6 Lines,8 Lines, 10 Lines |
Hole Size: |
25.4 Mm X 67 Mm |
Wire Diameter: |
2.0 Mm/2.2 Mm/2.4 Mm/2.7 Mm And So On |
Roll Length: |
110-295 M |
Amount Of Zinc: |
Up To 300 G/m2 |
Product Name: |
Subsea Force Reingrid Subsea Pipeline Reinforced Mesh |
Key Words: |
Offshore Pipeline Counterweight Welded Wire Mesh |
Material: |
Cold Or Hot-dip Galvanized |
Line Wire Quantity: |
6 Lines,8 Lines, 10 Lines |
Hole Size: |
25.4 Mm X 67 Mm |
Wire Diameter: |
2.0 Mm/2.2 Mm/2.4 Mm/2.7 Mm And So On |
Roll Length: |
110-295 M |
Amount Of Zinc: |
Up To 300 G/m2 |
Subsea Force Reingrid Subsea Pipeline Reinforced Mesh
Galvanized Wire Pipeline Reinforced Mesh Description:
Pipeline Reinforced Mesh also known as pipeline reinforcement mesh, pipeline mesh, marine reinforcement mesh, etc., is a welded mesh commonly used for the reinforcement of concrete counterweight coated pipelines. Marine reinforcement mesh is a popular product in the world industry and is used for concrete counterweight coating of offshore oil and gas pipelines. Marine reinforcement mesh is suitable for compression and impact coating processes. The diameter wires are deeply curled to facilitate the application of concrete coating. The material used is galvanized mild steel. It can be cold-dip galvanized iron wire or hot-dip galvanized wire deeply curled to facilitate application in concrete. Three specifications of marine reinforcement mesh are available with traditional 10 wire, 8 wire or 6 wire mesh systems. Pipeline reinforcement mesh is mainly used for concrete counterweight coating of submarine pipelines. In addition to conventional specifications, we also supply other specifications that can be customized according to customer requirements
Galvanized Wire Pipeline Reinforced Mesh Specification:
| Product Name |
Eight Lines Galvanized Wire CWC Pipeline Reinforced Mesh |
| Material | Galvanzied wire |
| Wire diameter | 2.0mm/2.2mm/2.4mm/2.7mm etc. |
| Mesh Hole size | 25.4mm x 67mm |
| Width dimensions | 190.5mm |
| Length dimensions | 140m/280m |
| Exposed Wire Edge | ≤ 2.5 mm |
| Roll Diameter | 700mm-1150mm |
| Technique | Point Welded |
|
Ref Number |
Main Wire (mm) |
Cross Wires (mm) |
Roll Width Dimensions (mm) |
Roll Length Dimensions (mm) |
|
CWC20 |
2.0@25.4 |
2.0@67 |
190.5 |
140/280 |
|
CWC22 |
2.2@25.4 |
2.2@67 |
190.5 |
140/280 |
|
CWC24 |
2.4@25.4 |
2.4@67 |
190.5 |
140/280 |
|
CWC27 |
2.7@25.4 |
2.7@67 |
190.5 |
140/280 |
Galvanized Wire Pipeline Reinforced Mesh Four Types:
Galvanized Wire Pipeline Reinforced Mesh Advantage:
l High quality material wire
l Standard wire diameter and hole size
l Enough roll width and roll length
l High tensile strength
l Strong anti-corrosion, anti-rust
l Strong welded point
l High degree of flexibility
l Long service life
l Easy to install
l Cost savings
Galvanized Wire Pipeline Reinforced Mesh Usage:
• Offshore oil and gas pipelines
• Subsea and underwater pipelines
• Underground water supply / drainage pipelines
• Concrete weight coating reinforcement
• Coastal and marine engineering pipeline protection
